Hydraulic Shaftless Mill Roll Stand
Product Details:
- Grade Automatic
- Type Other
- Material Metal
- Computerized Yes
- Control System PLC Control
- Voltage 380 Volt (v)
- Warranty 1 Year
- Click to view more
Hydraulic Shaftless Mill Roll Stand Price And Quantity
- 15000 USD ($)/Set
- 1 Set
- 12000.00 - 20000.00 USD ($)/Set
Hydraulic Shaftless Mill Roll Stand Product Specifications
- Metal
- Yes
- 1 Year
- PLC Control
- 380 Volt (v)
- Other
- Automatic
Hydraulic Shaftless Mill Roll Stand Trade Information
- Tianjin, Qingdao, Shanghai, Ningbo
- Western Union Paypal Letter of Credit at Sight (Sight L/C) Telegraphic Transfer (T/T)
- 100 Set Per Month
- 20 Days
- plastic film and wooden shipping crate
- All India
- ISO9001
Product Description
Corrugated Cardboard Hydraulic Shaftless Reel Paper Mill Roll Stand
Description of Hydraulic Shaftless Mill Roll Stand
Hydraulic Mill Roll Stand//Corrugated Cardboard Mill Roll Stand/Paperboard Mill Roll Stand: Symmetrical structure, can carry two craft paper at one time, which can work without brake. Reel paper lift-lower, clamp, loosen, movement, contraposition operated by hydraulic pressure. feeding craft/reel paper quickly.
Technical Parameters of Hydraulic Shaftless Mill Roll Stand
Maximum paper roll diameter: 1500mm
Effective width: 900-2000mm
Maximum support weight: 3t
Main axis: 242mm
Pneumatic Source Pressure: 0.4-0.8Mpa
Magnetic Valve Voltage: 380V 50HZ
Working pressure: 16-18Mpa
Features of Hydraulic Shaftless Mill Roll Stand
*Each arm setup four directions button, it is easy to operate
*It can be loading two paper rolls at the same time, without stopping the machine for changing the paper roll
*The whole machine uses 6 cylinders fully hydraulic controlled, hydraulic control arm lift and down, clamping and open, left and right moving
*Tension control: multipoint pneumatic brakes, brakes good performance, loses heat fast
*The chuck adopts inner expansion type or teeth type, reducing the destruction of the paper core. saving paper.
